UC3200
৳ 6,883
UC3400
৳ 9,474
Key Features
Number of Controller Modules : 2
CPU Model : Intel Xeon D-1541 (per controller)
CPU Quantity : 1 (per controller)
CPU Core : 8 (per controller)
CPU Architecture : 64-bit
System Memory : 8 GB DDR4 ECC UDIMM (per controller)
Memory Module Pre-installed : 8 GB (8 GB x 1) (per controller)
Share:
Specification
| Controller | ||
| Number of Controller Modules | 2 | |
| CPU | ||
| CPU Model | Intel Xeon D-1541 (per controller) | |
| CPU Quantity | 1 (per controller) | |
| CPU Core | 8 (per controller) | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 2.1 (base) / 2.7 (turbo) GHz | |
| Hardware Encryption Engine | - | |
| Memory | ||
| System Memory | 8 GB DDR4 ECC UDIMM (per controller) | |
| Memory Module Pre-installed | 8 GB (8 GB x 1) (per controller) | |
| Total Memory Slots | 4 (per controller) | |
| Maximum Memory Capacity | 64 GB (16 GB x 4) (per controller) | |
| Notes | Synology reserves right to replace modules. Use Synology modules for warranty. | |
| Storage | ||
| Drive Bays | 12 | |
| Max Drive Bays with Expansion | 36 (RXD1219sas x 2) | |
| Compatible Drive Type* | 2.5" dual-port SAS SSD | |
| Compatible Drive Type* | 3.5" dual-port SAS HDD | |
| Hot Swappable Drive* | - | |
| Notes | Only Synology-validated drives guarantee full functionality. | |
| External Ports | ||
| RJ-45 1GbE LAN Port | 2 (per controller, with LACP/Failover) | |
| RJ-45 10GbE LAN Port | 1 (per controller) | |
| PCIe | ||
| PCIe Expansion | 1 x Gen3 x8 slot (x8 link, per controller) | |
| Add-In-Card Support | 10GbE/25GbE NIC, FC HBA | |
| File System | ||
| Internal Drives | Btrfs | |
| Appearance | ||
| Size (H x W x D) | 88 × 430.5 × 692 mm | |
| Size (H x W x D) | 88 × 482 × 724 mm (with ears) | |
| Weight | 19.7 kg | |
| Rack Installation Support* | 4-post 19" rack (RKS-02 Rail Kit) | |
| Notes | Rail kit sold separately. | |
| Others | ||
| System Fan | 60 × 60 mm × 2 (per controller) | |
| Fan Speed Mode | Full-Speed/Cool/Quiet | |
| Easy Replacement System Fan | - | |
| Power Recovery | - | |
| Noise Level* | 51.3 dB(A) | |
| Power | ||
| Power Supply Unit | 500W (Redundant) | |
| AC Input Voltage | 100-240V AC | |
| Power Frequency | 50/60Hz, Single Phase | |
| Power Consumption | 239.25W (Access) | |
| British Thermal Unit | 816.35 BTU/hr (Access) | |
| Notes | Tested with Synology HAS5300 drives (noise/power). | |
| Temperature | ||
| Operating Range | 0°C to 35°C (32°F to 95°F) | |
| Storage Range | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
| Certification | ||
| - | CE, FCC, BSMI, VCCI, RCM, UKCA, KC, EAC | |
| Warranty | ||
| - | 3 years (extendable to 5 years) | |
| Environment | ||
| RoHS Compliant | - | |
| Packaging | ||
| - | Main Unit ×1, Accessory Pack, Power Cords ×2, Quick Guide | |
| Accessories | ||
| - | DDR4 ECC UDIMM (8GB/16GB) | |
Description
Synology NAS
A Network Attached Storage (NAS) provides a centralized location on a network to store data. A Synology NAS goes beyond that, enabling you to build a private cloud to store, access, back up, and share files freely and securely.
Intelligent data management on your own private cloud
Customize storage to fit your needs
Access and share your files intuitively
Store, archive, and process petabytes of data
Customize storage to fit your needs
Access and share your files intuitively
Customize storage to fit your needs
Synology NAS empowers you to securely store terabytes of data at your home, without any of the monthly fees that come with cloud storage. Our NAS and expansion units support a variety of hard disks (HDD) and flash drives (SSD), allowing you to adjust and expand your storage to fit your needs.
Access and share your files intuitively
Providing you with simple options to store, access, and share data is what a Synology NAS does best. Upload files at the speed of your local connection, share them quickly through secure sharing links, and access them from any browser, desktop, or mobile device.
Back up your PCs and Macs automatically
Keep files synced across all your devices with the Synology Drive private cloud. Drive also allows you to restore documents to a previous version when things go wrong. If you are using macOS, you can use Time Machine to back up files to your Synology NAS.
Safeguard and organize your media
Let Synology Photos automatically back up photos and videos taken on mobile devices. To save you time, the system groups media based on people appearing in them, places they were shot at, and more.
